A window with a substrate made of single-crystal silicon. No absorption in the infrared region up to 6μm. With anti-reflective (AR) coating on the both faces, the product delivers even superior transmission properties highly suitable for windows.
Features
- The AR-coated model offers high transmission properties for a wide range of light (3μm-5μm).
- The product can be used as a window forspecimen observation, laser irradiation, etc.
Typical Specifications
Model | SIWI | |
Wavelength Range | 3 – 5μm or 2 – 6μm | |
AR Coating | Y | N |
Reflectance | < 2.0% | – |
(One Side) | ||
Size | Φ25 x 1tmm, Φ30 x 1tmm | |
Substrate | Single-crystal silicon | |
Parallelism | Within 3 minutes | |
Scratch-Dig | 60-40 | |
Effective Diameter | 80% of the actual diameter |
Wavelength Characteristics of Reflectance(AR-coated)
ength Characteristics of Reflectance(AR-uncoated)
